Garage Plan with Flex Room | Associated Designs

living sq ft:

1434 sq ft

2nd floor sq ft:

538 sq ft

garage sq ft:

896 sq ft

dimensions:

32'-0"W × 28'-0"D

building height:

21'-10"

floors:

2

primary style:

Craftsman

secondary styles:

Country

collections:

Plans Now, 2 Story House Plans, Garage, Garage w/Living, Carports, Small House Plans

Designer Notes

Garage Doors are 10' (w) x 8' (t)

primary foundation:

Concrete Slab

building lot type:

Level Lot

primary roof pitch:

8/12

roof framing:

Truss

snow roof load:

25 psf.

primary wall type:

2x6 Wood Frame

exterior wall material:

Siding/Shingle

main floor ceiling height:

9'-0"

interior features:

Hobby Room

garage:

2 Cars

garage orientation:

Front Entry

garage features:

Recreation Room

Construction Drawing Packages:

Each plan set is drawn at 1/4"=1' scale and includes the following drawings:

Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.

Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.

Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.

Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.

Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.

Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.

Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.

Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.

Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
