Charming Craftsman accents draw your attention to the Elk Cove Concept Plan. The vaulted covered porch transitions seamlessly into the impressive vaulted foyer. To the left, a double set of pocket doors opens to the den. This space is ideal for a home office with it's suggested desk space and storage cabinets. The great room fills the back of the home and is completely open to the kitchen with its eye-catching curved eating bar. For those that love the outdoors, the Elk Cove offers extended outdoor living with the large, vaulted covered patio that features a fireplace with built-in pizza oven - perfect for entertaining! The owners' suite fills the back, right corner of the floor plan. This luxurious retreat offers his-and-hers walk-in closets, luxurious bathroom with soaking tub and exterior access to a private patio with enough room for a hot tub. Secondary bedrooms along with a TV loft are on the second floor.
Elk Cove 31-224
Photographs may show modifications made to plans. Copyright owned by designer.
At a Glance
-
4656
Square Feet
-
4
Bedrooms
-
3
Full Baths
-
2
Floors
-
2
Car Garage
More About The Plan
Contact ADI Client Support Specialist
Contact ADI Experts
Have questions? Help from our customer support specialists is just a click away.
Let’s be social
Connect with us for the latest from HPC
Plan Details
Basic Details
living sq ft:
4656 sq ft
1st floor sq ft:
3417 sq ft
2nd floor sq ft:
1239 sq ft
garage sq ft:
896 sq ft
craft room sq ft:
538 sq ft
dimensions:
97'-0"W × 71'-0"D
building height:
28'-9"
bedrooms:
4
full baths:
3
half baths:
1
floors:
2
primary style:
Craftsman
collections:
Concept House Plans, 2 Story House Plans, 4 Bedroom House Plans, View Lot House Plans, House Plans with Detached Garage
Designer Notes
Concept plan package includes PDF and DWG files of the: Elevations Floor Plan (s) Roof Outline The concept plan package can save you valuable time and resources by providing the essentials of the design allowing for a local designer, architect, or engineer to complete the construction documents to the building practices, requirements, and site conditions in your area. Concept plans include an unlimited build license (non-transferable).
