This one-story detached garage plan masterfully blends functionality with comfort, offering a three-car garage with tandem parking options and a stylish one-bedroom apartment above. Perfect for additional storage, guest lodging, or generating rental income, this design is both versatile and thoughtfully crafted.
Garage 20-574
Photographs may show modifications made to plans. Copyright owned by designer.
At a Glance
-
2736
Square Feet
-
1
Bedrooms
-
1
Full Baths
-
1
Floors
-
3
- 6
Car Garage
More About The Plan
Contact ADI Client Support Specialist
Contact ADI Experts
Have questions? Help from our customer support specialists is just a click away.
Let’s be social
Connect with us for the latest from HPC
Plan Details
Basic Details
living sq ft:
2736 sq ft
1st floor sq ft:
916 sq ft
garage sq ft:
1820 sq ft
porch sq ft:
160 sq ft
dimensions:
38'-0"W × 80'-0"D
building height:
22'-6"
bedrooms:
1
full baths:
1
floors:
1
primary style:
Craftsman
secondary styles:
Country
collections:
Accessory Structures, 1 Story House Plans, Garage, Garage w/Living, Carports, New House Plans
