Name: Garage w/ Living - 20-276
Brand: Associated Designs
SKU: 101 - 20-276
Availability: InStock

living sq ft:

912 sq ft

1st floor sq ft:

912 sq ft

garage sq ft:

1596 sq ft

porch sq ft:

160 sq ft

dimensions:

38'-0"W × 74'-0"D

building height:

20'-6"

bedrooms:

1

full baths:

1

floors:

1

primary style:

Craftsman

secondary styles:

Country, Farmhouse

collections:

Accessory Structures, 1 Story House Plans, Narrow Lot House Plans, Small House Plans, New House Plans

primary foundation:

Concrete Slab

building lot type:

Narrow Lot (<45'), Level Lot, Corner Lot

primary roof pitch:

7/12

roof framing:

Truss

snow roof load:

50 psf.

primary wall type:

2x6 Wood Frame

alternate wall types:

2x4 Wood Frame

exterior wall material:

Batten Board, Stone

exterior & porch features:

Covered Porch

main floor ceiling height:

8'-0"

kitchen features:

Eating Bar or Peninsula

utility room features:

Close to Kitchen or Garage, Main Floor Utility Room

master suite features:

Main Floor Master Suite

interior features:

Casual or Open Style Living Room, Great Room

garage:

4 Cars

garage type:

Attached

garage orientation:

Side Entry

garage features:

Oversized

Construction Drawing Packages:

Each plan set is drawn at 1/4"=1' scale and includes the following drawings:

Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.

Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.

Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.

Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.

Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.

Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.

Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.

Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.

Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
