Summerdale 31-013

  • Mediterranean House Plan - Summerdale 31-013 - Front Exterior Icon_ionic-ios-expand

Photographs may show modifications made to plans. Copyright owned by designer.

  • Mediterranean House Plan - Summerdale 31-013 - Front Exterior
  • Mediterranean House Plan - Summerdale 31-013 - Rear Exterior
  • Mediterranean House Plan - Summerdale 31-013 - Left Exterior
  • Mediterranean House Plan - Summerdale 31-013 - Right Exterior
  • Mediterranean House Plan - Summerdale 31-013 - 1st Floor Plan
1 of 6

At a Glance

  • Square Footage: Total Living 3317 Square Feet
  • Bedrooms 4 Bedrooms
  • Baths Full 4 Full Baths
  • Floors 2 Floors
  • Garage Bays Min 2 Car Garage

More About The Plan

Floor plan

1 of 2
Mediterranean House Plan - Summerdale 31-013 - 1st Floor Plan Icon_ionic-ios-expand
Contact us icon

Contact ADI Client Support Specialist

Contact ADI Experts

Have questions? Help from our customer support specialists is just a click away.

Plan Name: Summerdale
Plan Number: 31-013
Your submission has been received!
item-icon

Free modification quote

Call Us 541-461-2082 or fill out our form.

Get Started
item-icon

Cost to build report

How Much Will This Plan Cost To Build?

Find Out
A single review set of the construction drawings marked Not For Construction and do not include a license to build. Upgrade to a licensed construction package or sign on for modifications within 1 year of purchase and received a 100% upgrade credit.
Five printed sets of construction drawings plus a Print PDF (non-modifiable, print only). Includes a single build license.
Best Value
A digital copy of the construction drawings in a PDF format (non-modifiable, print only). Includes a single build license with permissions to make copies of the plan locally as needed. The PDF Print Package is emailed saving shipping costs and time.
A digital copy of the construction drawings in a PDF format. Includes a single build license with modification permissions so a local professional with compatible software can make changes to the plan. PDF Files are emailed saving shipping costs and time.
A digital copy of the construction drawings in a DWG file format. Includes a single build license with permissions which allow the plan to be modified and reproduced locally. CAD Masters are emailed saving shipping costs and time.
Unlimited Build
A digital plan package which includes both the PDF Master and CAD Master (DWG) and includes an unlimited build license.

Select a Foundation type

Standard

Select a Wall type

Standard
1
This option is not available for package '1 Set Study Package'
$0.00
$0.00
Quantity of Additional Sets
1
$0.00
Subtotal of Plan Package and Options
$1,475.00
GetQuote

Free modification quote

Are you looking for additional
plan options?

Get a Quote

Have questions? Prefer to order by phone? Give us a call: 541-461-2082

Adding to Cart… The item has been added

Plan Details

Basic Details

living sq ft:

3317 sq ft

1st floor sq ft:

1920 sq ft

2nd floor sq ft:

1397 sq ft

garage sq ft:

515 sq ft

dimensions:

54'-0"W × 66'-0"D

building height:

28'-10"

bedrooms:

4

full baths:

4

half baths:

1

floors:

2

primary style:

Mediterranean

secondary styles:

European, Tuscan

collections:

Luxury House Plans, 2 Story House Plans, 4 Bedroom House Plans, View Lot House Plans, Sloped Lot House Plans

Building Details

primary foundation:

Basement

alternate foundations:

Crawl Space, Concrete Slab

building lot type:

Rear View, View Lot, Downhill Sloping Lot

primary roof pitch:

6/12

roof framing:

Combination Stick/Truss

snow roof load:

25 psf.

primary wall type:

2x6 Wood Frame

alternate wall types:

2x4 Wood Frame

exterior wall material:

Stucco, Stone

exterior & porch features:

Balcony, Covered Porch, Deck, Grand Entrance

Interior Details

main floor ceiling height:

9'-0"

kitchen features:

Breakfast Nook/Dining Area, Eating Bar or Peninsula, Kitchen Island, Large Kitchen, Luxurious Kitchen, Walk-In or Wall Pantry

utility room features:

Close to Kitchen or Garage, Main Floor Utility Room

master suite features:

Exterior Access, Luxurious Master Bathroom, Private Toilet, Second Floor Master Suite, Separate Tub & Shower, Walk In Closet

interior features:

Beverage Bar, Den, Office, Library, or Study, Fireplace/Wood Stove, Formal Living Room or Parlor, Great Room, Guest Room, Suite, or Apartment, Walk-Out/Daylight Basement

Garage

garage:

2 Cars

garage type:

Attached

garage orientation:

Front Entry

What's Included in a Plan Set?
