A traditional duplex plan, the Dalian, was designed with investment properties in mind while still adding pleasant aesthetics to the neighborhood. With three levels filled with bedrooms and bathrooms and two units, this plan is functional while still affording each tenant privacy and a communal place to gather.
Dalian 60-050
Photographs may show modifications made to plans. Copyright owned by designer.
At a Glance
-
4320 Square Feet
-
10 Bedrooms
-
10 Full Baths
-
3 Floors
-
2 Car Garage
More About The Plan
Plan Details
Basic Details (All Units Combined)
living sq ft:
4320 sq ft
1st floor sq ft:
1086 sq ft
2nd floor sq ft:
1932 sq ft
garage sq ft:
600 sq ft
3rd floor sq ft:
1482 sq ft
dimensions:
40'-0"W × 54'-8"D
building height:
39'-7"
bedrooms:
10
full baths:
10
floors:
3
primary style:
Traditional
secondary styles:
Country
collections:
5 or More Bedroom House Plans, Narrow Lot House Plans, Duplex or Multi-Family Plans
Unit A Basic Details
LIVING SQ FT:
2160
1ST FLOOR SQ FT:
453
2ND FLOOR SQ FT:
966
GARAGE SQ FT:
300
GARAGE:
1 car
BEDROOMS:
5
FULL BATHS:
5
FLOORS:
3
Unit B Basic Details
LIVING SQ FT:
2160
1ST FLOOR SQ FT:
453
2ND FLOOR SQ FT:
966
GARAGE SQ FT:
300
GARAGE:
1 car
BEDROOMS:
5
FULL BATHS:
5
FLOORS:
3
Building Details
primary foundation:
Crawl Space
building lot type:
Narrow Lot (<45'), Level Lot
primary roof pitch:
5/12
roof framing:
Combination Stick/Truss
snow roof load:
25 psf.
primary wall type:
2x6 Wood Frame
exterior wall material:
Siding
exterior & porch features:
Balcony, Covered Porch
Interior Details
main floor ceiling height:
9'-0"
second floor ceiling height:
9'
kitchen features:
Kitchen Island, Walk-In or Wall Pantry
utility room features:
Close to Kitchen or Garage
interior features:
Great Room
Garage
garage:
2 Cars
garage type:
Attached
garage orientation:
Rear Entry, Side Entry
What's Included in a Plan Set?
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Concept Plan Packages:
Includes PDF and DWG files of the:
Elevations
Floor Plan (s)
Roof Outline
The concept plan package can save you valuable time and resources by providing the essentials of the design allowing for a local designer, architect, or engineer to complete the construction documents to the building practices, requirements, and site conditions in your area. Concept plans include an unlimited build license (non-transferable).
