Name: Garage - 20-097
Brand: Associated Designs
SKU: 101 - 20-097
Availability: InStock

living sq ft:

841 sq ft

garage sq ft:

841 sq ft

dimensions:

32'-4"W × 26'-0"D

building height:

22'-4"

floors:

1

primary style:

Shingle-Style

secondary styles:

Cape Cod, Craftsman

collections:

1 Story House Plans, Garage, Garage w/Living, Carports, Small House Plans, New House Plans

primary foundation:

Concrete Slab

building lot type:

Level Lot

primary roof pitch:

10/12

roof framing:

Combination Stick/Truss

snow roof load:

30 psf.

primary wall type:

2x6 Wood Frame

alternate wall types:

2x4 Wood Frame

exterior wall material:

Shingles

main floor ceiling height:

9'-0"

garage:

3 Cars

garage orientation:

Front Entry

garage features:

Attic Space
