The traditional one-story carport is designed with functionality and classic style in mind. Measuring 24' by 24', it provides generous space for sheltering two vehicles side by side. The structure sits on a gravel foundation, a practical choice that ensures proper drainage and long-lasting support for the carport while keeping construction efficient and straightforward.
Carport 20-233
Photographs may show modifications made to plans. Copyright owned by designer.
At a Glance
-
576
Square Feet
-
1
Floors
-
2
Car Garage
More About The Plan
Contact ADI Client Support Specialist
Contact ADI Experts
Have questions? Help from our customer support specialists is just a click away.
Let’s be social
Connect with us for the latest from HPC
Plan Details
Basic Details
living sq ft:
576 sq ft
carport sq ft:
576 sq ft
dimensions:
24'-0"W × 24'-0"D
building height:
18'-10"
floors:
1
primary style:
Traditional
collections:
Accessory Structures, 1 Story House Plans, Narrow Lot House Plans, Small House Plans, New House Plans, Garage, Garage w/Living, Carports
Building Details
primary foundation:
Not Available
building lot type:
Narrow Lot (<45'), Level Lot
primary roof pitch:
6/12
roof framing:
Stick
snow roof load:
20 psf.
primary wall type:
6x6 Posts
exterior wall material:
Posts
Interior Details
main floor ceiling height:
10'-0"
Garage
garage:
2 Cars
garage orientation:
Front Entry
garage features:
Carport/Port Cochere
What's Included in a Plan Set?
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc.
Section & Details: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation. Specific details such as fireplaces, stairways, decks, etc. are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Concept Plan Packages:
Includes PDF and DWG files of the:
Elevations
Floor Plan (s)
Roof Outline
The concept plan package can save you valuable time and resources by providing the essentials of the design allowing for a local designer, architect, or engineer to complete the construction documents to the building practices, requirements, and site conditions in your area. Concept plans include an unlimited build license (non-transferable).
